Wingtra WingtraRAY MAP61 Payload

Description

The MAP61 is Wingtra’s most efficient mapping payload— a 61 MP, obliquely mounted full-frame sensor that captures wide 93° swaths for high-resolution 2-D orthos and detailed 3-D models in a single grid. Cover up to 460 ha / 1,140 ac per flight at 2.7 cm / 1.06 in GSD and process data twice as fast thanks to 50 % fewer images.

Key Benefits

• High-res capture — 61 MP sensor delivers down to 1.2 cm / 0.47 in GSD.
• Oblique mount — 15° tilt records façades and vertical assets in a single pass.
• Wide 93° FOV — Less overlap, fewer images, faster flights & processing.
• Proven accuracy — PPK horizontal / vertical RMS down to 2 cm / 0.8 in & 4 cm / 1.6 in with no GCPs.
• Seamless workflow — Plan, fly, and process inside WingtraCLOUD for same-day insights.

Specs

MAP61 Technical Specifications

Sensor	61 MP full-frame, focal-plane shutter
Lens / focal length	17 mm (0.67 in) wide-angle, 15° oblique
Field of view	Horizontal 93° (-47°…+47°) • Vertical 70° (-20°…+50°)
Lowest GSD	1.2 cm/px (0.47 in/px) @ 180 ft (54 m)
Max coverage @ 400 ft*	460 ha (1,140 ac) @ 2.7 cm/px (1.06 in/px)
Max coverage @ lowest GSD*	200 ha (500 ac) @ 1.2 cm/px (0.47 in/px)
Accuracy (PPK, no GCPs)	Horizontal 2 cm (0.8 in) • Vertical 4 cm (1.6 in) RMS
Pixel dimensions	9 504 × 6 336
Minimal trigger time	0.5 s • Min. trigger distance 8 m (26 ft)
Payload weight (incl. mount)	585 g (1.29 lb)
Shutter type	Focal-plane mechanical
*Coverage assumptions	60 % side-overlap, calm conditions

In the Box

(1) MAP61 payload module with 61 MP sensor
(1) Oblique quick-lock mount (pre-installed)
(1) Protective lens cap
(1) Payload transport sleeve
(1) Quick-start & safety guide

Compatibility

WingtraRAY
